Laser Tube Cutting Services.
Precision laser cutting for round, square, and rectangular tubes with complex cutouts and features.
Round Tube Cutting
Laser cutting for round tubes from 0.5" to 6" diameter.
Square & Rectangular Tube
Laser cutting for square and rectangular tubes up to 6" dimension.
Precision Laser Tube Cutting
Laser tube cutting is the process by which tube stock material is selectively cut to form various shapes, holes, designs, and/or channels using a controllable precision laser. The stock material (tube/pipe) is held in a controllable lathe, where the tube will rotate in line with the design specifications as the laser makes cuts.
Laser tube cutting can create through-holes of any shape as small as the wall thickness of the material and is also often used to cut channels that allow for easy bending and welding of the tube for angled tubing.
Precision
Tolerances ±0.010" typical
Complex Features
Holes, slots, notches, and patterns
Multiple Materials
Steel, stainless, aluminum, alloy steel
Fast Cutting
Quick turnaround with no tooling
Operational Logic
Sizes and Tolerances
| Specification | Value |
|---|---|
| Minimum Round OD | 0.500" (12.7mm) |
| Maximum Round OD | 6.000" (152mm) |
| Minimum Square/Rect | 0.500" (12.7mm) |
| Maximum Square/Rect | 6.000" (152mm) |
| Minimum Wall Thickness | 0.035" (0.9mm) |
| Maximum Wall Thickness | 0.500" (12.7mm) |
| Edge-to-Edge Tolerance | ±0.010" nominal |
| Minimum Feature Size | Generally no larger than tube thickness |
Materials
| Material | Round Tube | Rectangular Tube | Square Tube |
|---|---|---|---|
| Aluminum | 6061 Extruded, 6061 Drawn | 6061 Extruded | 6061 Extruded |
| Stainless Steel | 304/316 Welded, 304/316 Seamless | 304/316 Welded | 304/316 Welded |
| Alloy Steel | A513 HREW/CREW/DOM, 4130 Seamless | A513, 4130 Seamless | A513, 4130 Seamless |
Advantages
Get Started with Laser Tube Cutting
Upload your files for instant pricing.
