Injection Molding Services.
Xofah provides a comprehensive range of injection molding services, delivering high-quality plastic parts from prototyping to production across various industries.
Plastic Injection Molding
Cost-effective production of plastic parts at scale with consistent quality and wide material selection.
Quick Turn Molding
Rapid injection molding with lead times as low as 5 business days for fast prototyping.
Production Molding
High-volume production molding from 250 to 1,000,000+ units with steel tooling.
Material Selection
50+ production-grade materials including engineering plastics and elastomers.
What Is Injection Molding?
Injection molding is the most cost-effective way to make a plastic part at scale. The injection molding process involves injecting molten plastic into a mold tool, then ejecting the solidified part. This process quickly repeats hundreds or thousands of times, amortizing the cost of the mold tool and driving down the cost of each unit to a few dollars or less.
Since the injection molding process uses the same mold tool for each part, it offers consistent quality across every part. Injection molding also has the highest variety of materials, colors, cosmetics, polishes, and surface textures when compared to CNC machining or even 3D printing.
Xofah's custom plastic mold service provides on-demand prototype and production molding. We take a customer-first approach which means we find the right injection molding supplier within our manufacturing supplier network to mold the parts the way you need them—without design compromises—at the right price point.
Quality Certified
ISO 9001, AS9100, ISO 13485, UL, ITAR certified facilities
Fast Turnaround
Starts at 5 business days with fast quote responses
Global Network
Domestic and international production options
Expert Support
Dedicated project managers on every order
Operational Logic
+/- 0.005" (0.127mm)
+/- 0.002" (0.05mm)
25 to 1000+ Tons
Class 101: 1M+ Cycles
Material
Matrix.
Commodity Plastics
Engineering Plastics
Performance Polymers
Elastomers (LSR/TPE)
Injection Molding Capabilities
| Service | Details |
|---|---|
| Lead Time | Starts at 5 business days, including fast quote responses with DFM feedback |
| Production Options | Domestic and international |
| Materials | Most plastics, including custom sourcing and matching |
| Machines Available | Single, multi-cavity, and family molds; 50 to 1,100+ press tonnage; side actions including hand-loaded cores |
| Inspection Options | Includes FAI and PPAP. ISO 9001, AS9100, ISO 13485, UL, ITAR, and ISO 7/8 Medical Clean Room molding |
| Tool Ownership | Customer-owned with mold maintenance |
| Mold Cavity Tolerances | +/- 0.005" when machining the mold and an additional +/- 0.002" per inch when calculating for shrink rate |
| Part to Part Repeatability | +/- 0.004" or less |
| Critical Feature Tolerances | Tighter tolerances can be requested and may increase the cost of tooling |
| Available Mold Types | Steel and aluminum; Production grades range from Class 105 (prototype) to Class 101 (high production) |
Xofah Injection Molding Mold Classes
Standard injection mold tooling is defined by classes from Class 105 (prototype) to Class 101 (high volume production). These mold classes help manage expectations for both customers and suppliers on the overall tool requirements and scope.
Class 105 Mold
Under 500 cycles. Prototype only. Least expensive construction for minimal quantity of prototype parts.
Class 104 Mold
Under 100,000 cycles. Low production mold. Aluminum or MUD tooling, limited production runs.
Class 103 Mold
Under 500,000 cycles. Medium production mold. Most popular for low to medium-production needs.
Class 102 Mold
Medium to high production tooling. High-quality, steel tooling with automated features.
Class 101 Mold
Over 1,000,000 cycles. Highest-quality materials for extremely high production.
Custom Plastic Injection Molding Materials
Rigid Plastic Materials
Wide selection of engineering-grade thermoplastics for various applications.
Elastomer and Rubber Materials
Flexible materials for seals, gaskets, and soft-touch applications.
Custom Injection Mold Finishes
Standard Finish
Moldmaker's choice of finish. Typically SPI B-2, depending on geometry and drafts.
SPI Finishes
Range from Grade 3 diamond/high polish to 320 stone low polish. Includes SPI A-1 through D-3.
MoldTech Finishes
Range of textures including matte, swirls, lines, and patterns. Common: MT11010, MT11020, MT11030.
VDI Textures
VDI 3400 Surface Finish standard producing fine to coarse matte finishes via EDM machining.
Threaded Inserts
Installation of standard inserts in UNF and metric sizes.
Pad Printing
Transfer 2D images onto 3D parts.
Laser Engraving
Engrave part numbers, logos, and more onto parts.
Assembly
Assemble and label injection molded parts.
Custom Injection Molding Design Guidelines
| Feature | Tip |
|---|---|
| Undercuts | Reduce undercuts to decrease tool complexity and cost. Add pass-thru coring where possible. |
| Wall Thickness | Maintain even wall thickness to prevent sink and voids. Thinner walls reduce cycle time and costs. |
| Drafts | Ensure minimum draft angle of 0.5°, or up to 5° for medium textures. |
| Ribs/Gussets | Ribs should be 40-60% the thickness of outer walls and maintain draft. |
| Bosses | Design at 30% wall thickness depth with 30% edge groove. Attach to side walls or ribs. |
Applications and Advantages
Vetted Standards.
Ready to Start Your Injection Molding Project?
Get expert consultation and competitive pricing for your custom injection molded parts.
